UniLight 5mm PIN Strobe Light, 3Wx2, Short - White PIN5X-030x2-WE
HomeStore

UniLight 5mm PIN Strobe Light, 3Wx2, Short - White PIN5X-030x2-WE

UniLight 5mm PIN Strobe Light, 3Wx2, Short - White PIN5X-030x2-WE

$20.10
UniLight 5mm PIN Strobe Light, 3Wx2, Short - White PIN5X-030x2-WE—
$20.10

The Story

UniLight 5mm PIN Strobe Light, 3Wx2, Short - White PIN5X-030x2-WE

A world first in miniaturization with high light output: the lights from the PIN 5mm series!

Using an intricate production technique, high-performance LED chips are connected directly to an electrical cooling carrier and additionally glued. This way, with a minimal chip surface of only 3x3mm, an enormous light output can be generated and operated. The package includes four different light caps, the two round 5mm caps resembling traditional LEDs but providing up to 100 times the typical brightness with an emission angle of over 120°. The cooling and mounting pin on the back is only 3mm in diameter and can be integrated very easily even in narrowest places in rudders or the thinnest tail units.
The position light with 3W in x2 technology delivers impressive performance for model aircraft despite its compact size, it can therefore only be operated in strobe or flash sequences. Always monitor the temperature during operation.

Technical Data:

Performance: 3Wx2 reference power
Voltage: 8(12)V, 0.25A
Beam angle: >120°
Light intensity: ~65 Lumen RED
Light intensity: ~150 Lumen GREEN
Light intensity: ~250 Lumen WHITE
Dimension: D5x20mm
Weight: 2g (without cable)

Operating Voltage: 2S/8V or 3S/12V with additional resistor
Cable Length: 0.5m PTFE 0,14mm²
Dimensions: 5mm
Design: Round
Function: Navigation/Position Light
Delivery Content:
  • Equipped with 0.5m connection cable and pre-configured resistor for 2S.
  • Cap 5mm cylindrical - can be attached directly as an all-round light
  • Cap 5mm round, focussing - when attached directly, part of the light is strongly bundled towards the front as with the 5mm light-emitting diodes
  • Cap 7mm cylindrical - can be glued to the model and used as an alternative cover
  • Cap 5mm profile-shaped - can be attached directly and used as a small position light
Assembly Instruction:

The design features an exposed LED chip, which acts as a ceramic carrier and can be quite delicate. We reinforce this by adding adhesive to stabilize it mechanically, but it is still crucial to handle the components with care until they are securely installed in the model.

Warning Notice:

The position light with 3W in x2 technology delivers impressive performance for model aircraft despite its compact size, it can therefore only be operated in strobe or flash sequences. Always monitor the temperature during operation.

UniLight 5mm PIN Strobe Light, 3Wx2, Short - White PIN5X-030x2-WE - Image 2

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

UniLight 5mm PIN Strobe Light, 3Wx2, Short - White PIN5X-030x2-WE - Image 3

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

UniLight 5mm PIN Strobe Light, 3Wx2, Short - White PIN5X-030x2-WE - Image 4

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

UniLight 5mm PIN Strobe Light, 3Wx2, Short - White PIN5X-030x2-WE - Image 5

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

UniLight 5mm PIN Strobe Light, 3Wx2, Short - White PIN5X-030x2-WE - Image 6

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

Description

UniLight 5mm PIN Strobe Light, 3Wx2, Short - White PIN5X-030x2-WE

A world first in miniaturization with high light output: the lights from the PIN 5mm series!

Using an intricate production technique, high-performance LED chips are connected directly to an electrical cooling carrier and additionally glued. This way, with a minimal chip surface of only 3x3mm, an enormous light output can be generated and operated. The package includes four different light caps, the two round 5mm caps resembling traditional LEDs but providing up to 100 times the typical brightness with an emission angle of over 120°. The cooling and mounting pin on the back is only 3mm in diameter and can be integrated very easily even in narrowest places in rudders or the thinnest tail units.
The position light with 3W in x2 technology delivers impressive performance for model aircraft despite its compact size, it can therefore only be operated in strobe or flash sequences. Always monitor the temperature during operation.

Technical Data:

Performance: 3Wx2 reference power
Voltage: 8(12)V, 0.25A
Beam angle: >120°
Light intensity: ~65 Lumen RED
Light intensity: ~150 Lumen GREEN
Light intensity: ~250 Lumen WHITE
Dimension: D5x20mm
Weight: 2g (without cable)

Operating Voltage: 2S/8V or 3S/12V with additional resistor
Cable Length: 0.5m PTFE 0,14mm²
Dimensions: 5mm
Design: Round
Function: Navigation/Position Light
Delivery Content:
  • Equipped with 0.5m connection cable and pre-configured resistor for 2S.
  • Cap 5mm cylindrical - can be attached directly as an all-round light
  • Cap 5mm round, focussing - when attached directly, part of the light is strongly bundled towards the front as with the 5mm light-emitting diodes
  • Cap 7mm cylindrical - can be glued to the model and used as an alternative cover
  • Cap 5mm profile-shaped - can be attached directly and used as a small position light
Assembly Instruction:

The design features an exposed LED chip, which acts as a ceramic carrier and can be quite delicate. We reinforce this by adding adhesive to stabilize it mechanically, but it is still crucial to handle the components with care until they are securely installed in the model.

Warning Notice:

The position light with 3W in x2 technology delivers impressive performance for model aircraft despite its compact size, it can therefore only be operated in strobe or flash sequences. Always monitor the temperature during operation.
